The EKN0800GEP Series is a compact unmanaged industrial Gigabit Ethernet switch featuring eight 10/100/1000Base-T RJ45 ports, with PoE++ functionality available on four ports and a wide 44–56VDC power input. Designed for reliable Ethernet connectivity in demanding industrial environments, the switch supports IEEE 802.3af/at/bt PoE technology on Ports 1–4, with optional PoE power configurations of up to 30W, 60W, or 90W per PoE port.
The switch supports Auto MDI/MDI-X, IEEE 802.3x Flow Control, IEEE 802.3az Energy Efficient Ethernet, and Store-and-Forward switching for stable and efficient data transmission. It also supports STP, RSTP, and MSTP protocols for network redundancy and improved network reliability. With a fanless IP40 aluminum housing, DIN-Rail and wall-mount installation, and a wide operating temperature range of -40°C to +75°C, the EKN0800GEP Series is designed for industrial automation, surveillance, transportation, power, renewable energy, and other harsh-environment applications.
- 8 × 10/100/1000Base-T Gigabit Ethernet RJ45 ports
- Port 1–4 supporting IEEE 802.3af/at/bt
- Optional PoE power: up to 30W, 60W, or 90W per PoE port
- 44–56VDC wide-range power input
- Auto MDI/MDI-X
- Supports IEEE 802.3x Flow Control
- Supports IEEE 802.3az Energy Efficient Ethernet (EEE)
- Supports IEEE 802.3/802.3u/802.3ab/802.3z/802.3x
- Store-and-Forward switching
- Supports IEEE 802.3D/W/S STP/RSTP/MSTP protocols
- Supports DIN-Rail and wall-mount installation
- Industry-standard IP40 aluminum housing
- Wide operating temperature range: -40°C to +75°C (-40°F to +176°F)
- Unmanaged plug-and-play operation
- Designed for industrial Ethernet, PoE surveillance, automation, transportation, power, and other demanding applications
- CE and FCC compliant
