Mini Industrial Gigabit Ethernet Ring Switch, 1-Port RJ45 + 1-Port SFP (+PoE Option)
The Mini Industrial Gigabit Ethernet Switch is designed for industrial Ethernet communication and fiber-based network connectivity, featuring one 10/100/1000Base-T RJ45 port and one 1000Base-X SFP slot. Its redundant dual power input supports a wide 9–56V DC range, while the PoE version supports 11–56V DC input for greater power flexibility. The switch provides reliable data transmission with Full/Half-Duplex operation, auto-negotiation, Auto MDI/MDIX, IEEE 802.3az Energy Efficient Ethernet, and Store-and-Forward switching. With a compact fanless aluminum housing, -40°C to +80°C operating temperature, IP40 protection, and DIN-rail or wall-mount installation, it is well suited for industrial control, power systems, water infrastructure, rail transit, traffic monitoring, wind power, photovoltaic systems, and building automation.
- 1 × 10/100/1000Base-T Gigabit Ethernet RJ45 port
- 1 × 1000Base-X SFP slot for fiber optic connectivity
- Supports Full/Half-Duplex, Auto-Negotiation, and Auto MDI/MDIX
- IEEE 802.3az Energy Efficient Ethernet (EEE)
- Store-and-Forward switching
- Redundant dual power input with a wide 9–56VDC range
- PoE version supports 11–56VDC input
- Supports 9K-byte Jumbo Frames
- Compact, fanless aluminum housing with IP40 protection
- -40°C to +80°C operating temperature
- DIN-Rail and wall-mount installation options
- Designed for reliable industrial Ethernet and fiber communication in demanding environments
